Description Data Sheet Function Description Output Current Operation Voltage Operation Temp Package Type WSH130 Bipolar_(S/N:_50,70,120G) Hall Effect IC 20mA 2.4~26V -40~125°C TO92S, SOT-23 WSH130NL Unipolar (S:50,70,150G) Hall Effect IC 20mA 2.4~26V -40~125°C TO92S, SOT-23 WSH131 Omnipolar (S/N:100,150G) Hall Effect IC 20mA 2.4~26V -20~85°C TO92S, SOT-23 WSH132 Unipolar (N100,200,250G) Hall Effect IC with Built-in Pull-high resistor 20mA 2.4~24V -40~125°C TO92S, SOT-23 WSH133 Bipolar (S/N: 90G) Hall Effect IC with Built-in Pull-high resistor 20mA 2.4~24V -40~125°C TO92S, SOT-23 WSH134 Unipolar (S:250G) Hall Effect IC 20mA 2.4~26V -40~125°C TO92S, SOT-23 WSH231 Omnipolar (70,100,150G) Switch IC with 2 outputs 20mA 2.4~26V -40~90°C TO94, SOT-25 Adjustable Hall switch IC Datasheet Function Description Output Current Operation Voltage Operation Temperature Package Type WSH237 Adjustable Hall switch IC (S/N:500G) 1.5mA 3.0~12V -20~125°C TO94, SOT-25
